Background and Identification
Released in April 2013, the Acer Iconia A1-810 (model number NT.L2REE.002) is a 7.9" touchscreen tablet. It has a standard flash memory of 1GB, but there is also an accessible microSD card slot, where you can store external memory. The system is operated by Android, the latest update being Android KitKat 4.4.4.
The touchscreen is a multi-touch screen, meaning the surface or screen can recognize the presence of more than one touch on the surface. The screen resolution is 1024 x 768, meaning the width is 1024 pixels and the height is 768 pixels. The Acer Iconia comes in red and white. It also has a version with less storage space, at 8GB, compared to 16GB.
Troubleshooting
For information on common troubleshooting issues see
Acer Iconia A1-810 Troubleshooting
Specifications
Operating Systems
- Android
Dimensions
- 208.7 x 145.7 x 11.1 mm (8.22 x 5.74 x 0.44 in)
Display and Graphics
- Screen Size: 7.9 inch
- Touchscreen: Yes
- Screen Resolution: 1024 x 768
Processor
- Speed: 1.2 GHz
- Core: Quad-core (4 Core)
Memory
- Standard: 1 GB
- Memory Card Supported: microSD
Storage
- 16 GB
Battery Information
- Number of Cells: 2-cell
- Battery Chemistry: Lithium ion (Li-ion)
- Battery Capacity: 4960 mAh
Power Description
- Maximum Power Supply Wattage: 10W
Additional Information
Acer Iconia A1-810 User Manual
