Tools

These are some common tools used to work on this device. You might not need every tool for every procedure.

Background and Identification

Advent is a brand owned by Dixons Retail, a European electronics retailer founded in 1937. This company owns well-known computer retailers like Currys, Currys Digital, and PC World. These websites sell electronics from a variety of well-known manufacturers, including HP, Acer, Dell, and more. However, they also have their own brand, Advent. Advent computers no longer appear on the Curry’s PC World website, but the website still offers accessories, including chargers and keyboard replacements.

The Advent Modena M201 laptop includes an Intel Celeron T3500 processor with 3 GB of DDR3 memory and a 320 GB hard drive. It features a 15.6-inch widescreen light-emitting diode (LED) display with a resolution of 1366 by 768 pixels. It includes one card reader, three USB 2.0 ports, one LAN port, a VGA port, one headphone jack, and a microphone jack. The Advent Modena M201 includes one of the three following batteries: A14-S1-4S1P2200-0 (14.8v 2200mAh), A14-21-4S1P2200-0 (14.8v 2200mAh), A14-S5-4S1P2200-0 (14.6v 2200mAh).

According to a review of the Advent Modena M201 from TechRadar. the laptop has a vibrant screen and good usability but has weak performance and sub-par battery life. The Advent Modena M201 includes the name “Advent” in capital letters in the center of the laptop’s lower bezel.

Technical Specifications

CPU: Intel Celeron T3500 2.1GHz

Memory: 3GB DDR3

Hard Drive: 320GB Toshiba MK3265GSX

CD Drive: TSSTcorp CDDVDW TS-L633

Screen: 15.6" Widescreen LED (1366x768)

Video Card: Integrated Intel Mobile 4 series

Webcam: Integrated

Sound Card: High Definition Audio

Network Card: JMicron PCI Express Fast Ethernet Adapter
Realtek RTL8191SE-VA WLAN

Ports:

  • 1x Card Reader
  • 3x USB 2.0
  • 1x LAN
  • 1x VGA
  • 1x Headphone
  • 1x Microphone

Battery:

  • A14-S1-4S1P2200-0 (14.8v 2200mAh)
  • A14-21-4S1P2200-0 (14.8v 2200mAh)
  • A14-S5-4S1P2200-0 (14.6v 2200mAh)

Dimensions: 33.15 x 382 x 255 (HxWxD in mm)

Weight: 2.5kg

Made By: Shuttle A15IM
