Battery
Tools
These are some common tools used to work on this device. You might not need every tool for every procedure.
Troubleshooting
For solutions to common problems, visit the PadFone S Troubleshooting Guide
Background and Identification
The Asus PadFone S is the global version of the Asus PadFone X made by Asus. They are remarkably similar in specifications where the only differences are in the network connections that are specific to international standards the phone has. The main difference is that the PadFone S is sold internationally and cannot be bought in the U.S. and the Padfone X can only be found in the U.S. The phone was released on June 6, 2014. The PadFone S' model number is PF500KL.
The predecessor of the PadFone S is the PadFone Infinity. The PadFone S has the tough Gorilla Glass to prevent it from getting scratches.
Specifications
Date of Announcement: March 2014
Released On: June 6, 2014
Model: PadFone S PF500KL
Developer: Asus
Operating System: Android OS v4.4.2 KitKat
Display:
• Super IPS+ LCD
• 1080 x 1920
• 5 inch (127mm)
• Multitouch widescreen
• 441 ppi
• Corning Gorilla Glass
Rear Camera:
• 13 MP 4128 x 3096 pixels
• Autofocus, LED flash
• Geo-tagging, touch focus, facial detection
• Video 2160p @ 25fps, 1080p @ 30fps
Front Camera:
• 2 MP
• Video 1080 @ 30fps
RAM: 2 GB
Storage: 16 GB, 64 microSD
Wireless Connectivity: Wi-Fi 802.11 a/b/g/n/ac, dual band, Wi-Fi hotspot
Bluetooth: v4.0, A2DP
Battery: Non-removable Li-Po 2300 mAh battery
Dimensions: 5.65 x 2.85 x 0.39 in (143.4 x 72.5 x 10 mm)
Weight: 150 g (5.29 oz)
Colors: Titanium Black, Platinum White, Dark Ruby
