Bella Cucina Mini Cupcake Maker 13465 Disassembly
Tools
These are some common tools used to work on this device. You might not need every tool for every procedure.
Background and Identification
Released in 2013, Bella Cucina Mini Cupcake Maker 13465 can bake 7 cupcakes at a time. This device has no buttons so the green and orange indicators on the top cover light up as soon as the device is connected to the power supply. However, the green indicator dims when the internal temperature exceeds 165 °C . It has an outer plastic covering. It has sticker containing three small cupcakes on the top circular cover. The inside parts including the cupcake holders are made of black alloy steel. The weight of the device is around 2.5 pounds. Its dimensions is LxWxH11.41 x 8.86 x 4.53 inches.
Specification
Manufacturer : BELLA INC
Model : 13465(TSK -2182MF)
Color : Red
Material : Alloy Steel
Brand : Sensio Bella Cucina
input voltage : 120V~60Hz, 760W
Item Dimensions LxWxH11.41 x 8.86 x 4.53 inches
Item Weight : 2.5 Pounds
Total Resistance of Heating Coils : 19.7 ohm
baking tray : Non-Stick
LED : orange and green
