Wallpapers

Check out our Google Pixel 4 teardown wallpapers! Choose from iFixit or Creative Electron (X-ray) versions.

Background

The most often replaced Google Pixel 4 XL parts include the battery, screen, and charging assembly.

Technical Specifications

CPU: Qualcomm Snapdragon 855

Memory: 6 GB LPDDR4x

Storage: 64 GB or 128 GB

Display:

  • 6.3 inches diagonal with rounded corners
  • Flexible QHD+ OLED (3040 x 1440 resolution, 537 ppi)
  • Smooth Display technology (dynamic refresh rate up to 90 Hz)
  • Corning Gorilla Glass 5
  • 19:9 aspect ratio

Cameras:

  • Rear Cameras
    • 16 MP ƒ/2.4 telephoto with phase detect AF and OIS
    • 12.2 MP ƒ/1.7 wide-angle with dual-pixel phase detect AF and OIS
  • Front Cameras
    • 8 MP ƒ/2.0 wide-angle with fixed focus
    • 2 NIR (Near Infrared) cameras for biometric authentication

Ports and Connectivity:

  • Wi-Fi: 2.4 GHz + 5 GHz 802.11 a/b/g/n/ac 2x2 MIMO
  • Bluetooth 5.0 + LE (HD codecs: AptX, AptX HD, LDAC)
  • NFC
  • GPS + GLONASS
  • USB Type-C
  • USB 3.1 Gen 1
  • Single Nano SIM or eSIM
  • Wireless charging

Battery: 3700 mAh

Dimensions:

  • Size: 75.1 x 160.4 x 8.2 mm
  • Weight: 193 g

Additional Information

Google: Pixel 4 / 4 XL spec sheet

Google: Pixel Repair Center

Wikipedia: Google Pixel 4
