Tools

These are some common tools used to work on this device. You might not need every tool for every procedure.

Background

The Pixel Watch is an Android smartwatch developed by Google as part of its Google Pixel product line. It's the first Smartwatch released by Google. The Pixel Watch was first previewed during the Google I/O keynote in May 2022, officially announced on October 6, 2022, and released on October 13, 2022.

It contains 32 GB of internal storage and 2 GB of RAM. It launched at $349.

Identification

The Google Pixel Watch comes in three different color options: Matte Black, Polished Silver, and Champagne Gold. These case colors combine with different bands to create four different configurations:

  • Matte Black case / Obsidian Active band
  • Polished Silver case / Chalk Active band
  • Polished Silver case / Charcoal Active band
  • Champagne Gold case / Hazel Active band

The Pixel Watch features a rounded display with a domed design, with one button and one digital crown. Its model number can be found underneath the watch band mount closest to the button. There are three model numbers based on case color:

  • GQF4C (Matte Black)
  • GBZ4S (Polished Silver)
  • GWT9R (Champagne Gold)

Specifications

Sizes: 41 mm only

Display:

  • Always-on 1.2-inch AMOLED display (450 by 450 pixels, ~320 ppi, custom 3D Corning Gorilla Glass 5)

Platform:

  • Exynos 9110 (10 nm) chipset
  • Dual-core 1.15 GHz Cortex-A53
  • Mali-T720
  • 2 GB RAM + 32 GB internal storage

Operating System: Android Wear OS

Sensors: compass, altimeter, blood oxygen sensor, multipurpose electrical sensor, optical heart rate sensor, accelerometer, gyroscope, ambient light sensor

Battery:

  • 294 mAh

Wireless Connectivity:

  • LTE (only LTE models)
  • GPS, GLONASS, GALILEO, BDS
  • Wi-Fi 802.11 b/g/n 2.4GHz
  • Bluetooth 5.0

Miscellaneous Features:

  • Water-resistant 50 m / 5 ATM (IP68)
  • Fitbit health and fitness
  • ECG certified
  • Emergency SOS
  • Fall Detection (announced)

Additional Information

Google Pixel Watch Announcement Blog Post

Google Pixel Watch Official Tech Specs

GSMArena: Tech Specs

The Verge: Google Pixel Watch Review
