Tools

These are some common tools used to work on this device. You might not need every tool for every procedure.

Troubleshooting

Are you having issues with your JVC action camera?

There may be a solution on the JVC Adixxion GC-XA1BU Troubleshooting page.

Background and Identification

The JVC Adixxion (pronounced addiction) is an action camera/camcorder released to compete with the Go Pro and Contour style action camcorders. Like these cameras, it can easily be mounted to a helmet, bicycle handlebars, sunglasses, backpack... pretty much anything! It is extremely small and compact, allowing for maximum mobility.

One of the best features of the JVC Adixxion is the built-in wi-fi which allows you to upload photos and videos without having to wait until you are able to connect the device to a computer. You can even stream your videos live!

The camera is highly durable; being waterproof to a depth of up to 5 meters (16.4 feet), and shockproof up to 2 meters (6.5 feet), which means that the camera can withstand a drop from that height. Typically, those types of features require the purchase of an additional case. It is also freeze proof and dust proof, which makes it a great choice for your next trip around the world!

Specifications

Size and Weight

  • Height: 53mm (2 1/8")
  • Width: 74mm (2 15/16")
  • Depth: 35mm (1 7/16")
  • Weight with battery: 128g (0.28 lbs)

Camera

  • Image Sensor: 5M CMOS
  • Lens Type: Fixed Focus, 170 degree
  • Digital Zoom: 5x
  • Digital Image Stabilizer: Yes
  • White Balance: Auto & Manual
  • Exposure: Auto
  • Self-Timer: Yes

Video / Stills / Audio

  • Video Recording Format: MPEG-4 AVC/H.264 (MP4)
  • Video Recording Mode:
  • FHD: 1920x1080/30p, 15Mbps VBR
  • HD960: 1280x960/30p, 8.9Mbps VBR
  • HD60: 1280x720/60p, 13Mbps VBR
  • HD30: 1280x720/30p 6.7Mbps VBR
  • WVGA: 848x480/30p, 3.0Mbps VBR
  • Digital Stills: JPEG, 5 Megapixel
  • Audio Format: AAC

Other

  • Terminals: HDMI mini, USB mini (chargeable)
  • LCD: 1.5” color
  • Wi-Fi Function: Yes
  • PC Software: Wi-Video (for Windows, provided in camera)
  • Waterproof: To a depth of 5m (16.4 ft)
  • Shockproof: From a drop of 2m (6.5 ft)

Additional Information

Buy Used on Amazon

JVC Adixxion GC-XA1 Product Page

JVC Adixxion GC-XA1 Basic User Guide

JVC Adixxion GC-XA1 Detailed User Guide

JVC Adixxion GC-XA1 Brochure

JVC Adixxion GC-XA1 Firmware Update
