This is the Page for the Kenwood DRV-520 Dash cam. Here you can find troubleshooting to diagnose your problem, and guides to help you replace faulty parts if you need to.
Troubleshooting
Check out this device’s troubleshooting page:
Kenwood DRV-N520 Troubleshooting
Information
Manual Download (PDF):
http://manual.kenwood.com/en_contents/at...
Manufacturer’’s Website:
https://www.kenwood.com/usa/car/dashboar...
Specifications
Image sensor: 1/3 inch color CMOS
Recording Angles: Horizontal: 117 degrees, Vertical: 63 degrees
Lens: Wide-angle, F-number 2.0
Recording Resolution: Video max: 2.98 megapixels
Frame rate: 27fps
Recording Media: Micro SDHC card, 8GB-32GB (class 6 or more)
G-sensor Sensitivity: -4.0G to +4.0G (in .01 G increments)
Power Voltage: 14.4V (8.5 to 16V)
Current Consumption: 400mA
Temperature Range: -10C to 60C
Dimensions: W:79mm, H:22mm D:48mm
Weight: 77g (excluding cord)
Files:
Video:
- Recording format: MOV
- Video: H.264
- Audio: Linear PCM
Image:
- JPEG (max: 2304x1296)
