Tools
These are some common tools used to work on this device. You might not need every tool for every procedure.
Background and Identification
Produced by Motorola, the Moto C is a smartphone made mainly for emerging markets as a low-end phone. It was released on May 1, 2017, and was aimed to offer reasonable specs at a low price in an attempt to compete with Chinese manufacturers that offer low cost smartphones.
Its design features a 5-inch display, a 1.1 GHz quad-core processor, 1 GB of RAM , a 5MP rear camera, 2MP front camera, a 2,350 mAh battery, 4G connectivity, and Android 7. Users can choose between three colors: Metallic Cherry, Fine Gold, and Starry Black. Its cover is made of plastic and is removable. Volume controls and the on/off button are located on the right side of the case with firm pressure points.
Positive aspects of the Moto C include its bright IPS panel, its dual-SIM, SD card expansion, and the battery runtime. However, negatives include average camera performance and the long charge time.
Troubleshooting
If you want to diagnose whether your problem is software or hardware related—including backing up and restoring your device—download the Rescue and Smart Assistant app.
Technical Specifications
- Display: 5 in (13 cm) 854 x 480 pixels
- Chmodepset: MediaTek quad-core, 64-bit 1.1 GHz
- CPU: MediaTek MT6737T
- GPU: Mali-T720 MP2 (650 Mhz)
- Memory: 1GB of RAM,
- Storage: 8GB and up to 32GB of expandable external storage
- Front Camera: 2 MP
Rear Camera: 5 MP - Battery: 2350 mAh
- OS: Android 7.0 "Nougat"
- Colors: cherry, white, gold or black backcovers
- Weight: 154 g
- Dimensions: 145.50 mm x 73.60 mm x 9.00 mm
