Background and Identification
The Samsung Gear S2 3G is a smartwatch from Samsung that also functions as a standalone phone. It requires a connected data plan to function. The Samsung Gear S2 3G, in addition to these more advanced capabilities, also offers users interaction with a variety of watch apps and widgets, as well as basic fitness tracking capabilities.
The Samsung Gear S2 3G utilizes wireless charging. The device sits on a wireless charging dock that connects via USB adapter to an electric socket.
The wristband on the Samsung Gear S2 3G can be easily replaced by pushing the button between the wristband and the watch body. Then, the strap can be pulled upward and removed. A new strap can be pushed into the slot and clicked into place.
The Samsung Gear S2 3G was criticized for being expensive and having a limited battery life.
The Samsung Gear S2 3G has a circular touchscreen watch face connected to a buckle-strap wristband. The watch has a built-in NFC antenna, light sensor, heart rate sensor, and microphone. It also includes two physical buttons on the right side of the watch, one of which functions as a back button and one of which functions as a home/power button.
Specifications
- Dimensions: 44 x 51.8 x 13.4 mm
- Weight: 50.75 grams
- Battery: 300 mAh
- Sensors: Heart rate, Gyro, Accelerometer, Barometer, ambient light, GPS
- Storage: 4 GB internal
- Water Resistance: IP68
- RAM: 512 MB
- Display Size: 1.19 inch
- Display Resolution: 360 x 360 pixels
- Processor: 1.0 GHz
