Tools

These are some common tools used to work on this device. You might not need every tool for every procedure.

Background

The Samsung RF263BEAE is a 26 cu. ft. French Door Refrigerator designed with advanced features for optimal food storage and convenience. It incorporates Twin Cooling Plus® technology, which maintains separate airflows and precise temperature controls, ensuring food stays fresh. The refrigerator offers multiple compartments, such as humidity-controlled crispers, a deli drawer, and gallon door bins, along with spill-proof glass shelves. An in-door ice maker that can produce up to 10 pounds of ice is also included. The exterior is crafted from stainless steel, featuring hidden hinges for a seamless appearance. Digital controls provide easy temperature adjustments for both the refrigerator and freezer.

Technical Specifications

  • Dimensions: 35 3/4" W x 70" H x 33 1/4"D (without door panel)
  • Shipping Weight: 310 lbs.
  • Ice Maker: Yes, built-in
  • Water Dispenser: No
  • Control Type: Digital External Display (2 temperature zones)
  • Lighting: LED
  • Refrigerator Capacity: 16.9 cu. ft.
  • Freezer Capacity: 9.1 cu. ft.
  • Temperature Control: Twin Cooling Plus® system
  • Door Alarm: Yes
  • Adjustable Shelves: Spill-proof glass shelves (4 refrigerator shelves, 2 freezer shelves)
  • Door Bins: Gallon door bins (4 refrigerator door bins, 2 freezer door bins)

Samsung RF263BEAE Owners Manual
