Tools

These are some common tools used to work on this device. You might not need every tool for every procedure.

Troubleshooting

For information regarding any troubleshooting issues, please refer to the troubleshooting page.

Background and Identification

The Toshiba Satellite C875-S7304 was released in April 2012 as part of Toshiba’s refreshed C Series. As part of the C Series, it was aimed at budget-conscious consumers looking for an entry-level laptop equipped with Windows 8. With an Intel processor, a 17.3 inch display, and 500 GB of storage, the C875-S7304 offered respectable performance for routine tasks at a price of around $600. Upon a C Series refresh in June 2015, the C875-S7304 was discontinued.

The Toshiba Satellite C875-S7304 is easily identified by a small plaque on the underside of the laptop near the optical drive. The plaque includes the manufacturer’s name - Toshiba - and the model - Satellite C875-S7304.

Specifications

Operating System

  • Windows 8

Processor and Graphics

  • Intel Core i3-3100M Processor
    • (3MB Cache, 2.40GHz)
  • Mobile Intel HM76 Express Chipset
  • Mobile Intel HD graphics with shared graphics memory

Memory

  • Configured with 4GB DDR3 1600 MHz (max 16GB)
  • 2 main memory slots. One slot is occupied.

Storage Drive

  • 500 GB (5400 RPM) Serial ATA hard disk drive

Fixed Optical Disk Drive

  • DVD SuperMulti drive supporting 11 formats
    • Maximum Read speed and compatibility: CD-ROM (24x), CD-R (24x), CD-RW (24x), DVD-ROM (8x), DVD-R (8x), DVD-R DL (6x), DVD-RW (6x), DVD+R (8x), DVD+R DL (6x), DVD+RW (8x), DVD-RAM (5x)

Display

  • 17.3” diagonal widescreen TruBrite TFT display at 1600 x 900 native resolution (HD+)
    • Native support for 720p content
    • 16:9 aspect ratio
    • LED backlit

Sound

  • Built-in stereo speakers
  • TOSHIBA Audio Enhancements

Input Devices

  • Standard Keyboard with 10-key (black)
  • Touch pad pointing device with multi-touch control

Communications

  • HD Webcam and microphone
  • 10/100 Ethernet
  • Wi-Fi Wireless networking (802.11b/g/n)

Expandability

  • Memory Card Reader
    • Secure Digital, SDHC, SDXC, mini SD, micro SD, Multi Media Card [shared slot] - adapter may be required

Ports

  • Video
    • RGB
    • HDMI
  • Audio
    • Microphone input port
    • Headphone output port
  • Data
    • 2 USB v2.0 ports and 1 USB V3.0 port
    • RJ-45 LAN port
  • Security
    • Slot for Security Lock

Physical Description

  • Satin Black Trax
  • Dimensions (W x D x H Front/H Rear): 16.2” x 10.6” x 1.3”
  • Weight: Starting at 5.7 lbs., depending upon configuration

Power

  • 65W (19V 3.42A) 100-240V/50-60Hz AC Adapter
  • Dimensions (W x H x D): 4.21” x 1.85” x 1.20”
  • Weight: Starting at 0.55 lbs.

Battery

  • 6 cell/48Wh Lithium Ion battery pack
  • Battery Life Rating (measured by MobileMark Productivity 2012)
    • Included 6 cell battery: up to 3 hours and 53 minutes

Software

  • Toshiba Software and Utilities
    • TOSHIBA Audio Enhancements
    • TOSHIBA BookPlace
    • TOSHIBA Disc Creator
    • TOSHIBA eco Utility
    • TOSHIBA HDD Protection
    • TOSHIBA HW Setup Utility
    • TOSHIBA PC Health Monitor
    • TOSHIBA Media Player by sMedio Truelink+
    • TOSHIBA Maintenance Utility
    • TOSHIBA Recovery Media Creator
    • TOSHIBA Service Station
    • TOSHIBA Sleep Utility
    • TOSHIBA Supervisor Password Utility
    • TOSHIBA Resolution+ Upconvert Technology for Media Player
    • TOSHIBA Video Player
  • Third-party Software
    • Internet Explorer 10
    • Microsoft Essentials
      • Photo Gallery
      • Movie Maker
      • Skydrive desktop
    • Norton Laptop Checkup
    • Origin powered by EA Game Console
    • WildTangent Games Console
  • Special Offers and Trial Software
    • 1 month trial for new Microsoft Office 365 customers
    • Norton Internet Security 2013 (30-day trial subscription)
    • Norton™ Online Backup (30-day Trial)
    • Norton Anti-Theft (60-day Trial)

Warranty

  • 1 Year Standard Limited Warranty

Environmental Specifications

  • This product is RoHS compatible
  • ENERGY STAR Qualified
  • EPEAT Gold Rated

Source: Toshiba Satellite C875-S7304 Detailed Specifications
