Tascam Portastudio 05 Broken Play Switch

Difficulty

Moderate

Steps

4

Time Required

No estimate

Introduction

When your ON/OFF switch fails, follow this guide to get your Portastudio operational.

  1. Yrob6es63CYaSR6r
    Yrob6es63CYaSR6r
    1wrrfvsGln3wsOMU
    b1W1GXSSkRpSrIMG

    • Remove the power buton

    • Remove the screws from back

    • Gently open the device

  2. BGSxmV6mekOZovYp
    BGSxmV6mekOZovYp
    WCONEpD1S2NKcTmK
    RTGmEFLBVLbDVYF4

    • Remove this screws

    • The PLAY doesn't work because the plastic is broken. It holds a spring.

    • Gluing the plastic will not work, as spring pressure is too high.

  3. JgRHIEg1DvCalBsD
    JgRHIEg1DvCalBsD
    H2NCcTPKGS3tQqPB
    qDLHJAyxiosRSaCO

    • To make a good support for the spring, drill a hole on the metal and ADD a little screw.

  4. Y1TfVmSjIwk41xe6
    Y1TfVmSjIwk41xe6
    MrKWroqSKRP1hs5t

    • This little plug has the sound output of the four tracks split. You can add independent outputs from tape.

Conclusion

Para remontagem de seu dispositivo, siga estas instruções na ordem inversa.
