Battery
Strumenti
Questi sono alcuni strumenti di uso comune usati per lavorare su questo dispositivo. Potrebbe non essere necessario ogni strumento per ogni procedura.
Troubleshooting
The troubleshooting page is located here.
Background and Identification
The ASUS Vivobook Flip TP501U is a Windows 10 2-in-1 laptop that was released in the spring of 2016. The device is designed for portable use, targeting home and office use. The release price for the different configurations of the laptop ranged from $749 to $1099.
Reviews of the device most often praise the aesthetic of the device as well as its portability. Criticisms often include the poor quality screen and that it is more difficult to repair than previous models. Some users report poor performance, especially high disk usage when they first started using the laptop, however, this is common in Windows laptops during setup, and in general, the performance of the laptop was considered good.
The TP501 mainly differs from its predecessor the TP500 by its construction, as it is made with higher quality materials, and is slightly smaller and lighter. However, the battery is smaller than the earlier model. The TP501 was replaced by the TP510 in 2018, which is even thinner and lighter and has ASUS Pen support.
Specifications
Processor
Intel® Core™ i7 6500U Processor
Intel® Core™ i5 6200U Processor
Intel® Core™ i3 6100U Processor
Intel® Core™ i7 7500U Processor
Intel® Core™ i5 7200U Processor
Operating System
Windows 10
Memory
4 or 8 GB DDR3L 1600MHz SDRAM plus 1 SO-DIMM slot for expansion
Display
15.6" (16:9) LED-backlit HD (1366x768) 60Hz Touchscreen
Graphics
Integrated Intel HD Graphics 520
Storage
128 Gb SATA 3.0 M.2 SSD
Keyboard
Chiclet Keyboard
Card Reader
Multi-format SD card reader
WebCam
VGAWebcam
Network
Integrated WiFi 4
Bluetooth 4.0
Interface
1 COMBO audio jack
1 Type-C USB 3.0
2 Type-A USB 3.0
1 USB 2.0
1 RJ45 LAN jack
1 HDMI
1 SD card reader
1 Volume up/down
Audio
Built-in 1.6 W Stereo Speakers with Digital Microphone
Battery
2-Cell 38 Wh Polymer Battery
Power Adapter
Plug: 4mm
Output: 19 V DC, 2.37 A, 45 W
Input: 100-240 V AC, 50/60 Hz universal
Dimensions
377.7 x 253 x 22.5 mm (WxDxH)
Weight
2.2 kg
Additional Information
Best Buy’s Blog Page - Review
