Strumenti

Questi sono alcuni strumenti di uso comune usati per lavorare su questo dispositivo. Potrebbe non essere necessario ogni strumento per ogni procedura.

Background and Identification

Released in Mid-2012, the Asus Zenbook UX32VD was one of the first ultrabooks to feature laptop-sized performance in a small form-factor. The UX32VD features a dedicated Nvidia 620M, along with an Intel Core i7 processor. While slightly thicker than other ultrabooks of its generation, the UX32VD features an aluminum outer shell and a full 1080p display.

Specifications

  • Processor: Intel Core i5-3317U 1.7 GHz
  • Graphics adapter: NVIDIA GeForce GT 620M - 1024 MB, Core: 625 MHz
  • Memory: 4 GB 1600 MHz DDR3 Expandable
  • Display: 13.3 inch 16:9, 1920x1080 pixel, IPS, CMN1343
  • Mainboard: Intel HM76 (Panther Point)
  • Storage: Hitachi Travelstar Z5K500 HTS545032A7E380 + 24 GB SSD Cache, 320 GB, 5400 rpm, +24GB SSD Cache
  • Connections: 3 USB 3.0, 1 VGA, 1 HDMI Audio Connections: Headset Combo Card Reader: SD-Cardreader, Mini-VGA
  • Networking: 10/100 MBit Lan Adapter (10/100MBit), Intel Centrino Advanced-N 6235 (a/b/g/n), Bluetooth 4.0
  • Size: Height x Width x Depth (in mm): 18 x 326 x 223 ( = 0.71 x 12.83 x 8.78 in)
  • Weight: 3.2 lbs. / 1.47 kg
  • Battery: 48 Wh Lithium-Polymer
  • Operating System: Microsoft Windows 7 Professional 64 Bit
  • Additional features: 720p HD Webcam, Mini-VGA/VGA Adapter, USB 3.0/LAN Adapter

Troubleshooting

Troubleshoot and resolve common problems with this Troubleshooting Guide.
