Lenovo ThinkPad Edge E470

The Lenovo ThinkPad Edge E470 is a laptop that was designed for small/medium sized businesses that are used by professionals that need something reliable and efficient. The type of laptop model was introduced as part of the ThinkPad edge series. This series aims to blend business class and features with consumer oriented design elements.

The normal features of the ThinkPad Edge normally has a black matte finish and a durable build quality. As they were replaced around 2017, the E470 offered a lot of configuration for their computers. With intel core processors ( ranging from i3 to i7 ), up to 16GB of Ram, and with storage that could changed from an HDD to SDD. To wrap everything up the laptops also come with integrated Intel HD Graphics.

Like any electronic equipment, the ThinkPad Edge E470 is not impervious to possible problems despite its advantages. Common failure modes include overheating, gradual battery degradation, and hardware component failures, according to some customers' reports. Lenovo has not released any particular recalls for the E470.

This laptop was catered to tasks from everyday office work to more demanding applications like photo and video editing. The E470 have received successor with small improvements here and there and lead to their discontinuation in 2019 when Lenovo refresh its product lineup

The Lenovo ThinkPad Edge E470 is a professional-looking business laptop with a 14-inch display and ergonomic keyboard. It also has a trackpad with configurable buttons for the user’s convenience. The laptop has three USB ports, one HDMI port, an ethernet port, and a headphone jack for audio input and output.

Processor:

7th Generation Intel® Core™ i3 / i5 / i7 Processor

• i3-6100U: 2 Cores, 4 Threads, 2.3 GHz Base Frequency, 3MB Cache, DDR4-2133 Memory Controller, Intel HD Graphics 520 Processor Graphics
• i5-6200U: 2 Cores, 4 Threads, 2.3 GHz Base Frequency, 2.8 GHz Max Turbo Frequency, 3MB Cache, DDR4-2133 Memory Controller, Intel HD Graphics 520 Processor Graphics
• i7-6500U: 2 Cores, 4 Threads, 2.5 GHz Base Frequency, 3.1 GHz Max Turbo Frequency, 4MB Cache, DDR4-2133 Memory Controller, Intel HD Graphics 520 Processor Graphics
• i3-7100U: 2 Cores, 4 Threads, 2.4 GHz Base Frequency, 3MB Cache, DDR4-2133 Memory Controller, Intel HD Graphics 620 Processor Graphics
• i5-7200U: 2 Cores, 4 Threads, 2.5 GHz Base Frequency, 3.1 GHz Max Turbo Frequency, 3MB Cache, DDR4-2133 Memory Controller, Intel HD Graphics 620 Processor Graphics
• i7-7500U: 2 Cores, 4 Threads, 2.7 GHz Base Frequency, 3.5 GHz Max Turbo Frequency, 4MB Cache, DDR4-2133 Memory Controller, Intel HD Graphics 620 Processor Graphics

Graphics:

Intel HD Graphics in processor only, or NVidia GeForce 920MX Graphics, 2GB DDR3 memory, or NVidia GeForce 940MX Graphics, 2GB DDR3 memory, digital monitor support via HDMI™ (supporting HDCP to output protected content); supports dual independent displays; Max resolution: 1920x1080 (HDMI)@60Hz

Memory:

32GB max / 2133MHz DDR4, non-parity, dual-channel capable, two 260-pin SO-DIMM sockets

Display:

Some: 14.0" (355mm) HD (1366x768), anti-glare, LED backlight, 220 nits, 16:9 aspect ratio, 400:1 contrast ratio

Some: 14.0" (355mm) FHD (1920x1080), anti-glare, LED backlight, IPS, 250 nits, 16:9 aspect ratio, 400:1 contrast ratio

Some: 14.0" (355mm) FHD (1920x1080), anti-glare, LED backlight, 220 nits, 16:9 aspect ratio, 400:1 contrast ratio

Storage:

Some: SSD / SATA 6.0Gb/s, 2.5" wide, 7mm high, removable, upgradable

Some: HDD / SATA 6.0Gb/s, 2.5" wide, removable, upgradable, Active Protection System™

Ethernet:

Gigabit Ethernet Connection, Realtek R8111GUS

WLAN:

One of the following, configurable by model:

• Intel Dual Band Wireless-AC 8265, 2x2, Wi-Fi + BT combo adapter, M.2 Card
• QCA, Qualcomm 344A-AC, 2x2, Wi-Fi + Bluetooth combo adapter, M.2 Card
• QCA, Qualcomm 435-AC, 1x1, Wi-Fi + Bluetooth combo adapter, M.2 Card

Bluetooth™:

Bluetooth wireless, integrated in Wi-Fi + Bluetooth combo adapter

Multicard Reader:

4-in-1 reader (MMC, SD, SDHC, SDXC)

Ports:

Two USB 3.0 (one Always On), one USB 2.0, HDMI, Ethernet (RJ-45), combo audio/microphone jack

Dimensions:

Aluminum (WxDxH): 13.35" x 9.53" x 0.88"; 339mm x 242mm x 22.4mm

PC/ABS (WxDxH): 13.35" x 9.53" x 0.93"; 339mm x 242mm x 23.7mm

Weight:

From 4.12 lb (1.87kg)

Case color:

Black, Silver, Gold (in EMEA, only black color available)

Case material:

Aluminum: Aluminum display cover

PC/ABS: PolyCarbonate/Acrylonitrile-Butadiene-Styrene display cover

Camera:

Some: HD720p resolution, fixed focus

Audio support:

HD Audio, Conexant® CX11852 codec, Dolby® Audio™ Premium/stereo speakers, 2W x 2 / dual array microphone, combo audio/microphone jack

Keyboard:

6-row, spill-resistant multimedia Fn keys

UltraNav™:

TrackPoint® pointing device and multi-touch with 3+2 buttons click pad

Fingerprint reader:

Some: Fingerprint reader on the keyboard bezel, swipe sensor

Security:

Power-on password, hard disk password, supervisor password, security keyhole

Security chip:

fTPM2.0: Firmware TPM 2.0, integrated in chipset

dTPM2.0: Discrete TPM 2.0, TCG Certified

Battery type:

Li-Polymer 3-cell (45Wh)

Battery life:

3-cell (45Wh): up to 8.4 hr

AC adapter:

Some: 45-watt AC adapter

Some: 65-watt AC adapter

Some: 90-watt AC adapter

Preload:

Some: Windows 10 Pro 64

Some: Windows 10 Home 64

• Lenovo Companion
• Lenovo Settings
• Microsoft Office preloaded; purchase a product key to activate
• McAfee® Live Safe (30-day trial)

Limited warranty:

1-year - depot repair service/service upgrades available

Environment:

EPEAT™ Gold; ENERGY STAR®; RoHS-compliant

Source:

ThinkPad E470 Platform Specifications
