Strumenti

Questi sono alcuni strumenti di uso comune usati per lavorare su questo dispositivo. Potrebbe non essere necessario ogni strumento per ogni procedura.

Troubleshooting

If you are having difficulty with the MSI GS66 Stealth, try referring to the Troubleshooting Page

Background

The MSI GS66 Stealth is a laptop computer by the NVIDA Corporation released on June 24th, 2021. This device comes in various models offering different accessory options for different models. This can range from different types of processors, graphics cards, RAM, etc. The base model of this laptop ranges from $1200 to $2800 for more advanced versions of the device. The laptop is known for being a powerful device used mainly for gaming on sperate platforms. It is good to keep in mind that this device comes in a variety of formats with different technical specifications depending on the respective user.

The MSI GS66 Stealth offers various options for a processor ranging from the Intel Core i7 for the base model and the i9 for the later generation models. The laptop has a moderate battery life of about 6 hours with high usage and comes with a more developed cooling system to account for the processing power of the device. This can also be seen in the size of the laptop itself; it weighs a little over 4.5 pounds with a 15.6-inch screen making it larger than most other laptops. The device offers 16 gigabytes of RAM (Random Access Memory) in the standard model and can range up to 32 gigabytes. The device comes with a high-definition display (1920x1080) or higher for other models and this is backed by a NVIDIA GeForce RTX Series GPU which the device is mostly known for.

Identification

The MSI GS66 Stealth 11UE-007 has a metal chassis and thin bezels surrounding its display. It has a backlit keyboard with RGB lighting. On the right side there is two USB Type-A ports, a USB Type-C port, an Ethernet port, and an audio jack. On the left side there is an HDMI port, a USB Type-A port, a USB Type-C port, and a Barrel Jack for the charger. The model number and specific specifications, such as storage capacity and RAM, can be found on a sticker on the bottom of the laptop, allowing for easy identification and verification of its configuration.



Technical Specifications

·       CPU: Core i7-11800H 8 Core

·       CPU Speed: 2.4 - 4.6GHz

·       Chipset: HM570

·       Color: Core Black

·       Screen Size: 15.6" FHD, Anti-Glare Wide View Angle 240Hz 3ms

·       Resolution: 1920x1080 (16:9)

·       GPU: NVIDIA® GeForce RTX™ 3060 Laptop GPU

·       Video Memory: 6G GDDR6

·       Keyboard: Steel Series per-Key RGB with Anti-Ghost key (84 Key

·       Audio: Nahimic 3 / Hi-Res Audio

·       Speaker: 2 x Dynaudio 2W Speakers

·       Memory: 16GB (8G*2) DDR4 3200MHz

·       HDD: 1TB NVMe SSD

·       LAN: Killer E3100 2.5GbE

·       WLAN: Killer Wi-Fi 6E AX1675 (2x2)

·       Bluetooth: BT 5.2

·       Webcam: IR 720p HD Webcam

·       USB: 3x USB 3.2 Gen2

·       Type-C Port: 1x Thunderbolt™ 4; 1x USB 3.2 Gen2/DP

·       Video Port: HDMI (supports 4K @ 120Hz, 8K @ 60Hz)

·       Audio Port: 1 Audio Combo (1/8")

·       AC Power Adaptor: 230W Slim

·       Battery Pack: 4 cells (99.9Whr)

·       Dimension: 14.17"x9.65"x0.71"

·       Weight: 4.63lbs

Additional Information

MSI GS66 Stealth Support Page

MSI GS66 Stealth Manufacturer’s Page

MSI GS66 Stealth Review Page
