Troubleshooting

There is currently no troubleshooting information available for the MacBook Air A1466.

Background and Identification

The MacBook Air model A1466 was released on June 11, 2012. This mid-2012 update includes all that is on the previous model including Apple's Thunderbolt port, backlit keyboard, and an upgrade to USB 3.0.

This model is the fifth iteration of MacBook Air. It is the same thickness as the previous model. It is visibly distinguished by the model number, A1466, on the underside of the machine and the MagSafe 2 power adapter.

Technical Specs

Display:

  • 13.3-inch (diagonal) high-resolution LED-backlit glossy widescreen display with support for millions of colors

Storage:

  • 128GB, 256GB, or 512GB Flash Storage

Processor:

  • 1.8GHz dual-core Intel Core i5 with 3MB shared L3 cache or 2.0GHz Intel Core i7 with 4MB shared L3 cache

Memory:

  • 4G or 8G of 1600MHz DDR3L on board memory

Wireless Connectivity:

  • 802.11n Wi-Fi wireless networking;3 IEEE 802.11a/b/g compatible
  • Bluetooth 4.0 wireless technology

Graphics and Video:

  • Intel HD Graphics 4000
  • Thunderbolt digital video output
  • 720p FaceTime HD camera

Ports:

  • Two USB 3 ports (up to 5 Gbps)
  • Thunderbolt port (up to 10 Gbps)
  • MagSafe 2 power port
  • SD card slot

Dimensions:

  • Height: 0.11-0.68 inch (0.3-1.7 cm)
  • Width: 12.8 inches (32.5 cm)
  • Depth: 8.94 inches (22.7 cm)
  • Weight: 2.96 pounds (1.35 kg)
