Strumenti

Questi sono alcuni strumenti di uso comune usati per lavorare su questo dispositivo. Potrebbe non essere necessario ogni strumento per ogni procedura.

Background

The Razr 40 is the minimalist, budget version of Motorola's 2023 Razr lineup. Released alongside the Razr+, this model follows up on the 2019 Razr Gen 1, having skipped the 2021 release of a foldable phone. The 1.5 inch (3.81 cm) external display provides quick information and notifications without needing to fully open the phone. It provides mid-range performance and top-tier battery life compared to similar models. The backing is a vegan leather instead of a full-size external display, as seen on the Razr+ (or Razr 40 Ultra).

Identification

The Razr 40 is most notably recognized by the external build. The large rear camera bezel contains the 1.5 inch (3.81 cm) OLED display among the rear cameras. Above the camera bezel is the soft vegan leather finish, either in Sage Green, Summer Lilac, or Vanilla Cream colors.

Technical Specifications

Build

  • Dimensions
    • Closed: 73.95 × 88.24 × 15.80 mm (2.9 × 3.5 × 0.6 inches)
    • Open: 73.95 × 170.82 × 7.35 mm (2.9 × 6.7 × .29 inches)
  • Weight: 188.6 g (6.65 oz)
  • Glass: Corning® Gorilla® Glass Victus® (external display cover)
  • Body: 7000 series aluminum (frame), Vegan leather (finish)
  • Durability rating: IP52 Water-repellent

Display

  • Main Display (opened)
    • 6.9 inches (17.53 cm), 2640 ×1080 pixels (22:9), 413 ppi
    • 85.5% screen-to-body ratio
    • AMOLED, 10-bit, LTPO, DCI-P3 color gamut
    • HDR10+
    • 144 Hz refresh rate
    • 240 Hz touch rate (normal), 360 Hz (game-mode)
    • 1400 nits
  • External Display (closed)
    • 1.5 inches (3.81 cm) 194 × 368 pixels (2:1), 282 ppi
    • AMOLED, 8-bit, DCI-P3 color gamut
    • 60 Hz refresh rate
    • 120 Hz touch rate
    • 1000 nits

Hardware

  • Processor: Snapdragon 7 Gen 1
  • Memory: 8 GB LPDDR4X
  • Storage: 256 GB UFS 2.2
  • Sensors
    • Side button fingerprint reader
    • Proximity sensor
    • Ambient light sensor
    • Ultra-sonic sensor
    • Accelerometer
    • Gyroscope
    • eCompass
    • Hall Sensor
    • Barometer
    • Face-unlock
  • Front camera (opened)
    • 32 MP ƒ/2.4, 0.7 µm, or 8 MP 1.4 µm Quad Pixel
    • Fixed focus
    • UHD @ 30 fps, FHD @ 30 or 60 fps
  • Rear cameras
    • 64 MP ƒ/1.7, 0.7 µm, or 16 MP 1.4µm Quad Pixel
    • 13 MP ƒ/2.2, 1.12 µm 120° FOV
    • Wide, Macro
    • Normal: UHD 30 fps, FHD 30 or 60 fps
    • Wide and Macro: UHD and FHD 30 fps

Battery

  • Capacity: 4200 mAh
  • Charging
    • 30W TurboPower™ charging support
    • 33W charger included
    • 5W wireless charging support

Audio

  • Dual stereo speakers with Dolby Atmos® and Spatial Sound
  • No 3.5 mm headphone jack
  • Three microphones

Connectivity

  • 5G
    • sub-6: N1/2/3/5/7/8/20/26/28/38/40/41/66/77/78
  • 4G
    • LTE (Cat18)
    • B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28/32/38/39/40/41/42/43/48/66
  • 3G
    • UMTS / HSPA+
    • GSM QB; W1/2/4/5/8
  • 2G: GSM / EDGE
  • NFC: Yes
  • Bluetooth: Bluetooth® 5.3
  • SIM Card: eSIM and Nano SIM
  • Wi-Fi
    • 802.11 a/b/g/n/ac/ax/Wi-Fi 6e
    • 2.4 GHz & 5 GHz & 6 GHz
    • Wi-Fi hotspot
  • Location Services: GPS, A-GPS, LTEPP, SUPL, GLONASS, Galileo, Beidou

Rescue and Smart Assistant: https://en-us.support.motorola.com/app/r...

Repair FAQ: https://en-us.support.motorola.com/app/r...

Razr 40 User Guide: https://en-us.support.motorola.com/app/a...
