Guide Sostituzione

Screen Protector

Screen Protector

 en

Strumenti

Questi sono alcuni strumenti di uso comune usati per lavorare su questo dispositivo. Potrebbe non essere necessario ogni strumento per ogni procedura.

Background

The first generation Motorola Razr made a comeback back in 2019, honoring the iconic Razr phone from the mid-2000's. Motorola skipped the release of a 2021 model, going straight to the 2023 release of the Razr+. This high-end smartphone appeals to a wide market, advertised as a daily phone that integrates functions like video chat, photography, and texting as now leveraging benefits from the phone's fold-ability. The cover screen on the Razr+ is nearly edge-to-edge, high resolution, and blends behind the rear cameras. This phone still features a teardrop-shaped hinge design, but now with an IP52 durability rating.

Identification

You can easily identify the Motorola Razr+ by the large external display and rounded edges of the aluminum frame. When opened, the screen has a slightly raised perimeter to allow the screen to fully shut without contacting itself.

Technical Specifications

Build

  • Dimensions
    • Closed: 73.95 × 88.42 × 15.1 mm (2.9 × 3.5 × 0.6 inches)
    • Open: 73.95 × 170.82 × 6.99 mm (2.9 × 6.7 × .28 inches)
  • Weight: 184.5 / 188.5 g (6.53 oz)
  • Glass: Corning® Gorilla® Glass Victus® (external display cover)
  • Body: 7000 series aluminum (frame), Vegan leather (finish)
  • Durability rating: IP52 Water-repellent

Display

  • Main Display (opened)
    • 6.9 inches (17.53 cm), 2640 ×1080 pixels (22:9), 413 ppi
    • 85.1% screen-to-body ratio
    • AMOLED, 10-bit, LTPO, 120% DCI-P3 color gamut
    • HDR10+
    • 165 Hz refresh rate
    • 240 Hz touch rate (normal), 360 Hz (game-mode)
    • 1400 nits
  • External Display (closed)
    • 3.6 inches (9.14 cm) 1066 × 1056 pixels (1:1), 413 ppi
    • AMOLED, 10-bit, 100% DCI-P3 color gamut
    • 144 Hz refresh rate
    • 120 Hz touch rate (normal), 360 Hz (game-mode)
    • 1100 nits

Hardware

  • Processor: Snapdragon 8+ Gen 1
  • Memory: 8 GB LPDDR5
  • Storage: 256 GB UFS 2.2
  • Sensors
    • Side button fingerprint reader
    • Proximity sensor
    • Ambient light sensor
    • Ultra-sonic sensor
    • Accelerometer
    • Gyroscope
    • eCompass
    • Hall Sensor
    • Barometer
    • Face-unlock
  • Front camera (opened)
    • 32 MP ƒ/2.4, 0.7 µm, or 8 MP 1.4 µm Quad Pixel
    • FHD / UHD @ 30 or 60 fps
  • Rear cameras
    • 12 MP ƒ/1.5, 1.4µm
    • OIS 13 MP ƒ/2.2, 1.12 µm 120° FOV
    • Ultra-wide, Macro
    • Normal: UHD / FHD @ 30 or 60 fps
    • Wide and Macro: UHD / FHD 30 fps

Battery

  • Capacity: 3800 mAh
  • Charging
    • 30W TurboPower™ charging support
    • 5W wireless charging support

Audio

  • Dual stereo speakers with Dolby Atmos® and Spatial Sound Qualcomm® Snapdragon Sound™
  • No 3.5 mm headphone jack
  • Three microphones

Connectivity

  • 5G
    • sub-6: N2/5/7/12/13/14/25/26/29/30/38/41/48/66/70/71/77/78
  • 4G
    • LTE (Cat20)
    • B1/2/3/4/5//7/8/12/13/14/17/18/19/20/25/26/28/29/30/38/39/40/41/46/48/66/71
  • 3G
    • UMTS / HSPA+
    • GSM850/900/1800/1900; W1/2/4/5/8
  • 2G: GSM / EDGE
  • NFC: Yes
  • Bluetooth: Bluetooth® 5.3
  • SIM Card: eSIM, Nano SIM, Dual SIM (Nano-SIM, dual stand-by)
  • Wi-Fi
    • 802.11 a/b/g/n/ac/k/v/r/ax/Wi-Fi 6e
    • 2.4 GHz & 5 GHz & 6 GHz
    • Wi-Fi hotspot
  • Location Services: GPS, A-GPS, LTEPP, SUPL, GLONASS, Galileo

Rescue and Smart Assistant: https://en-us.support.motorola.com/app/r...

Repair FAQ: https://en-us.support.motorola.com/app/r...

Razr+ FAQ: https://en-us.support.motorola.com/app/p...

Razr+ User Guide: https://en-us.support.motorola.com/app/a...
