Battery
Strumenti
Questi sono alcuni strumenti di uso comune usati per lavorare su questo dispositivo. Potrebbe non essere necessario ogni strumento per ogni procedura.
Background
The Series 5 UltraTouch (Model number: NP540U3C-A02UB) was released to the public in 2012. Equipped with a 13.3” screen and touch features. The Series 5 UltraTouch weighs 1.7 kilograms (3.73 lbs). The series 5 has a gigabit Ethernet port on the laptop's left side.
The laptop runs on an Intel Core i3 processor with a speed of 1.8 GHz combined with a 500 GB SATA Hard Drive. It also includes 4 GB of Random Access Memory (RAM). The laptop has an LED screen resolution of 1366 x768 and is equipped with a lithium polymer battery, allowing a battery life of up to 6.7 hours. It also has 2x2 W stereo speakers and a 1.3 MP camera.
Identification
The Series 5 UltraTouch laptop's outside case is gray. On the bottom of the laptop, there is a removable hard drive cover to easily upgrade or change out this component. The inside case is silver and the screen is glossy. Just above the black keyboard on the left-hand side is the label Series 5 Ultra.
To identify this laptop, there is a barcode on the back case with the number “MODEL CODE: NP540U3C”. If the label on the back of your device is missing, take a look at this article, How to find the model and serial number of my product, on the Samsung site.
Specifications
Dimensions
Width: 315 mm
Depth: 218 mm
Height (front): 17 mm
Height (rear): 20 mm
Weight
3.73 lb (1.7 kg)
Battery
Lithium Polymer Batteries
Four Battery Cells
7.4 V, 45 Wh battery
I/O Ports
2 USB 2.0 ports
USB 3.2 Gen 1 Type A port
Ethernet Lan (RJ-45) port
HDMI port
19V 2.1 A DC in jack
I/O Devices
2x 2 W Stereo Speaker
1.3 MP Camera
Intel Centrino Advanced-N 6235 Wireless Module, 802.11 a/b/g/n, Bluetooth 4.0
CPU
Dual Core Intel Core i3-3217U, 1.80GHz
Storage
500 GB HDD
RAM
4 GB DDR3
GPU
Intel HD Graphics 4000
Temperature/Humidity
Recommended temperature: 10°C - 32°C (50°F - 90°F)
Recommended humidity: 20 - 80% RH
Tjunction temperature: 105°C
Power Consumption
40 W (19 V, 2.1 A)
