Panasonic DMC-FZ70 LCD Screen Replacement

Scritto Da: Alberto Rodriguez

Commenti: 5

Panasonic DMC-FZ70 LCD Screen Replacement

Difficoltà

Moderate

Passi

Tempo Necessario

10 minuti

Introduzione

This guide will show you how to remove the LCD screen of your camera. If the screen is cracked or not working, you can use this guide to learn how to remove and replace it. Before you begin, make sure that the battery and SD card have been removed.

Strumenti

Passo 1

All screws should be removed using a Phillips #0 screwdriver.
Using your screwdriver, unscrew the two 5.0 mm Philips screws to the right of the LCD screen.

Passo 2

Flip the camera over to the left side of the screen and unscrew the 5mm Phillips screw found there.

Passo 3

Turn the camera upside down and unscrew the three 5mm screws found on the bottom.

Passo 4

On the top of the camera locate the two rails with a thin sheet of metal on the floor between them.
With a metal spudger, lift this sheet and push it out of the rail device to detach it from the camera.

Passo 5

Proceed to remove the four 5mm Phillips screws that you just uncovered.

Passo 6

Slowly pull on both side of the camera, until both halves begin to separate from each other.
Do not pull too hard, as both halves are held together with ZIF connector cables.

Passo 7

Using a plastic opening tool, carefully flip up the small black levers that attach the ribbon cables to the ZIF connectors on the motherboard.
Carefully pull the ribbon cables out of the slot once they have been released.
Only the two indicated connectors need to be removed to separate the two halves of the camera.
