Toyota Tundra 2nd generation (2007-2013) Tailgate Handle Replacement

Scritto Da: Brandon Gibson
  • Commenti: 3
Toyota Tundra 2nd generation (2007-2013) Tailgate Handle Replacement

Difficoltà

Moderate

Passi

9

Tempo Necessario

30 minuti

Introduzione

In this guide you will be replacing the tailgate handle. 2007-2013 Toyota Tundra - Tailgate Handle, Textured Black model number (690900C051) is the part you will be using. Make sure to go slow as these screws are very easy to strip. The broken tailgate handle needs to be replaced because you won’t be able to lift it up and down, causing the whole truck bed to be less usable. After this guide you should be able to use your truck bed to its fullest capacity as needed.

  1. yUSjaUM6KsgJPIdT
    yUSjaUM6KsgJPIdT
    A3CR6TAnndX3mj6R

    • Remove the Torx-head screws (23.2mm) on the inside panel of the tailgate, using the torx T25 screwdriver.

  2. gUExRsvCGRS2TKQT
    gUExRsvCGRS2TKQT
    Olyuamwvg2HhJEvB

    • Pull off the panel and then pull cables inward, causing tailgate to release and go down.

  3. fQ2B2IfjwCsXbaG2
    fQ2B2IfjwCsXbaG2
    6ruAtdwYeDDUrPXi

    • Remove rubber pieces from cable and pull cable from insert.

  4. DabxeqoVHHMdYGHX
    DabxeqoVHHMdYGHX
    CZjSFGlpUcYADsMS

    • Use your 5/16th-in. wrench to turn bolt counter clockwise and remove the bolts (18.5mm).

    What size it this blot ?

    Oneil Notlob -

  5. xhfcXUCMNxKcMWAc
    xhfcXUCMNxKcMWAc
    hDKB5y1klVeCHFEJ

    • Push in black clip to let handle fall out.

  6. 6LrELcwlVSaq4G26

    • Put new tailgate handle back in.

  7. QfBfEhtESOKdEKWc

    • Hand twist in bolts; then tighten with wrench.

  8. 2O5K5EJ5UOGbTJOO

    • Insert cable back into socket and press rubber lock onto cable.

  9. HgkPX2QC4cTEovFb

    • Put panel back into place and screw in using your torx -T25 screwdriver.

Conclusione

This Device is a medium hardness fix but, with hard-work it can be achieved in only about 30 minutes
