Background and Identification
The 17" NEC MultiSync LCD1770NX is a flat-panel monitor featuring a thin-frame design and fully adjustable stand. NEC Display Solutions released the LCD1770NX in 2004 as a new addition to their MultiSync line of CRT and LCD monitors. The LCD1770NX is aimed primarily for office users. Features include a 17 inch LCD screen with resolution up to 1280x1024, an adjustable stand, and four usb ports.
The LCD1770NX has a few identifying features that set it apart from other models. Look for the NEC logo on the front top-left corner and the words "Multisync LCD1770NX" on the front top-right corner of the monitor. Later models, such as the LCD1770NX-BK, may include a sound bar that attaches to the monitor.
Troubleshooting
For troubleshooting help, please visit our LCD 1770NX Troubleshooting page.
Specifications
Display
- Brightness 250.0 lumens
- Contrast ratio 450:1
- Display size 17.0 inches
- Color depth 16.2 Million Colors
- Viewable size 17.0 inches
- Aspect ratio 4:3
- Horizontal viewing angle 160.0ˆž°
- Vertical viewing angle 145.0°
- Response time 12.0 ms
- Resolution 1280 x 1024 pixels
- Refresh rate 75.0 Hz (60 Hz recommended)
Physical Dimensions
- Width 14.4 inches
- Depth 7.8 inches
- Height 14.3-18.6 inches
- Weight 13.2 pounds
