Nokia G22 Back Cover Removal
Tools
These are some common tools used to work on this device. You might not need every tool for every procedure.
Background
The Nokia G22 is an Android smartphone manufactured by HMD Global. It runs on Android 12.
The Nokia G22 was announced and released on February 25, 2023.
Identification
The Nokia G22 features a 6.5 inch panel with a V-Notch. The camera bump on the back cover is labeled "50 MP AI CAMERA”. Identified by model numbers TA-1516 or TA-1528.
The Nokia G22 is available in the colors Meteor Grey and Lagoon Blue.
Specifications
Models: TA-1516 (without NFC), TA-1528 (with NFC)
SoC: Unisoc Tiger T606
- 4 cores / 4 threads, 12 nm, 1 MB L3 cache
- 2x Arm Cortex A75 cores @ 1.6 GHz
- 2x Arm Cortex A55 cores @ 1.6 GHz
- Arm Mali-G57 MP1 GPU @ 650 MHz
Memory: 4 GB LPDDR4X
Storage: 64 GB
- MicroSD support up to 2 TB
Display:
- 6.5-inch 1600 x 720 pixels (~270 ppi, 90 Hz, Corning Gorilla Glass 3, V-Notch)
Cameras:
- Main camera: 50 MP, autofocus, f/1.8, 2 MP (Depth) and 2MP (Macro)
- Front-facing camera: 8 MP, fixed focus, f/2.0
Ports and Connectivity:
- Wi-Fi 802.11 a/b/g/n/ac (2.4/5GHz dual band)
- Bluetooth 5.0
- GPS/AGPS/GLONASS/BDS/Galileo
- USB Type-C
Battery:
- 5050 mAh Li-ion battery
- 20 W fast charging
Dimensions:
- Size: 165 x 76.19 x 8.48 mm (6.5 x 3.12 x 0.33 in)
- Weight: 195.23 g (6.89 oz)
Additional Features
- IP52 water/dust resistance rating
- Fingerprint (power button, optical)
- Ambient light sensor, proximity sensor, accelerometer (G-sensor)
- Biometric face unlock
- NFC (TA-1528 model only)
Exploded Diagram
Explosion-view diagram of the Nokia G22
