PlayStation 2 Slimline SCPH-700xx

SCPH-70000, SCPH-70001, SCPH-70002, SCPH-70003, SCPH-70004, SCPH-70005, SCPH-70006, SCPH-70007, SCPH-70008, SCPH-70009, SCPH-70010, SCPH-70011, SCPH-70012

The Sony Playstation 2 Slimline was released in September, 2004, in time for the launch of Grand Theft Auto: San Andreas. Production of the old models (SCPH-100xx – SCPH-500xx) stopped as soon as the smaller, thinner, quieter replacement hit the shelves (SCPH-700xx). Other than the noticeable size difference, Slimline models can be identified by a built-in ethernet port which previous models did not have.

Repairing the Playstation 2 Slimline is not a difficult task. The majority of disassembly can be done with a screwdriver and the components can be easily identified and swapped out without soldering.

The xx in the title is a placeholder for the different regional codes which are listed below:

• SCPH-70000: Japan
• SCPH-70001: Northern America (US and Canada)
• SCPH-70002: Oceania (Australia and New Zealand)
• SCPH-70003: United Kingdom and Ireland
• SCPH-70004: Europe, Middle East and Africa
• SCPH-70005: South Korea
• SCPH-70006: Hong Kong
• SCPH-70007: Republic of China (Taiwan)
• SCPH-70008: Russia
• SCPH-70009: People's Republic of China
• SCPH-70010: Mexico and South America (Argentina, Chile, Columbia, Peru)
• SCPH-70011: Northern America model with internal modem for both US and Canada
• SCPH-70012: Northern America model with internal modem for Canada

Looking for a place to start? Check out the troubleshooting page for solutions to common problems with the Playstation 2 Slimline.

• General
  • Manufacturer: Sony
  • Part Number: 97060
  • Model Numbers: SCPH-700xx
  • Media Type: DVD
  • CPU: Toshiba & Sony Emotion Engine - 294.9 MHz
  • RAM: 32MB RDRAM
  • Power Consumption: 45 Watts
• Video
  • Memory: 4MB
  • Max. Resolution Output: 1280 x 1024
  • System: NTSC / PAL
• Size
  • Width: 9.1 in
  • Depth: 6 in
  • Height: 1.1 in
  • Weight: 2 lbs
• External Connections
  • 2 x Game Controller
  • 2 x Memory Card
  • 2 x USB (4-pin, Type-A)
  • 1 x Network (RJ-45)
  • 1 x Phone Line (RJ-11)
  • 1 x Audio/Video Output
  • 1 x SPDIF Output
  • 1 x DC Power Input
