Battery
Tools
These are some common tools used to work on this device. You might not need every tool for every procedure.
Background and Identification
The Microsoft Surface Book 2 comes in several different variations. This page refers to the hybrid tablet/laptop computer with a 15 inch screen (measured diagonally). This computer may have an Intel i5-8350U or Intel i7-8650U processor. For many people, 15 inch laptops like this one hit the ‘Goldilocks zone’ of mobile computers. They’re not too big or small, and they have enough space for a good processor without sacrificing portability. However, this screen size is fairly large for a hybrid computer. Hybrid laptops, also called 2-in-1 laptops, have a touch screen and a detachable keyboard. When the keyboard is attached, the device functions like a regular laptop. When it is disconnected, the screen can be used as a tablet. 15 inches is very large for a tablet, but the large screen size may be preferable to some users. To find the model number of your Microsoft computer, use this guide from the Microsoft support website.
Technical Specifications
- Dimensions: 13.5 x 9.87 x 0.568-0.90in (343 x 251 x 15-23 mm)
- Screen: 15” PixelSense™ Display
- Resolution: 3240 x 2160, (260 PPI)
- Processor: 8th Gen Intel Core i5-8350U/ i7-8650U quad-core processor
- Graphics: Intel HD Graphics 620 integrated or NVIDIA GeForce GTX 1060 discrete
- RAM: 16 GB LPDDR3 RAM
- Storage: Solid state drive (SSD) options: 256GB, 512GB, or 1TB
- Front Camera: 5.0MP, 1080p HD video
- Rear Camera: 8.0MP, autofocus, 1080p HD video
- Microphones: Dual microphones
- Audio: Front-facing stereo speakers with Dolby Audio
- Wi-Fi: IEEE 802.11 a/b/g/n/ac compatible
- Bluetooth: Bluetooth Wireless 4.1 technology
- Xbox Wireless built-in
- Ports: 2 USB 3.0 Type A, USB Type-C, UHS-II SDXC card reader, 3.5mm headphone jack, 2 Surface Connect
- Casing: Magnesium
- Color: Silver
